What is System Designer?
System Designer provides a graphical interface for designing systems based on UML standards, allowing users to create components without coding. It acts as an Object-Document Mapper (ODM) to manage components as NoSQL documents, facilitating easy navigation and instantiation.
Once the model is designed, the tool generates method skeletons where users only need to add implementation code. It bundles the entire system—including models, components, and methods—into a JSON object, which can be installed and run in client or server applications using System Runtime, supporting composition of multiple bundles.
Features
- Graphical Design: Create systems using UML standards without coding
- Component Management: Act as an ODM to handle components as NoSQL documents
- Code Generation: Automatically generate method skeletons for behavior implementation
- System Bundling: Bundle models, components, and methods into a JSON object
- Deployment Support: Install and run bundles in client or server applications with System Runtime
Use Cases
- Designing software systems with UML diagrams
- Creating and managing components for web applications
- Generating code skeletons for system behaviors
- Bundling systems for deployment in Node.js or HTML applications
- Composing multiple system bundles for complex applications
